Udor IOTA-20/GR Diaphragm Pump

Udor IOTA-20/GR Diaphragm Pump

Brand:
Udor
Weight:
13.0 lb
Item #
IOTA20GR
1 review
Skip to product information
1 of 1

Udor IOTA-20/GR Diaphragm Pump

Udor IOTA-20/GR Diaphragm Pump

Brand:
Udor
Weight:
13.0 lb
Item #
IOTA20GR
1 review

Regular price $668.97
Sale price $668.97 Regular price List Price: $1,216.30

Free Shipping on Qualified Orders Over $100

In stock orders placed within

ship out same day. Learn more

Earn 2,007 points with this purchase.

View full details

Collapsible content

Product Overview

The Udor IOTA-20/GR diaphragm pump is built to last with anodized aluminum construction internally manifolded in the unit. With a maximum pump speed of 540 rpm, the IOTA-20/GR works great on three to five horsepower engines with _" shafts and a gear reduction. This pump weighs 17 pounds and has a maximum psi of 275.

Manufacturer description

Two diaphragm pump with pulsation dampener & control unit with adjustable pressure regulator, manual dump lever & pressure gauge. The "GR" version includes a gearbox with 3/4" hollow shaft for mounting to 3-6.5 hp gas engines. Also a replacement pump for any IOTA-17/GR. UDOR IOTA Series Pumps are internally manifolded with anodized aluminum construction. Features: Can Be Run Dry. Visual Oil Sight Gauges. Self-Priming Operation. Stainless Steel Check Valves. Large Capacity Oil Bath Crank Cases With Drain Plugs for Ease of Maintenance. Compatible with Most Fluids, Including: Liquid Fertilizers, Abrasive Materials, Suspension Products, Pesticides, De-Icing Materials and Other Hard To Handle Fluids. Adapt Easily To PTO, Gas Engine, Hydraulic And Belt Drive Applications. Maximum Fluid Temperature, 140° F. Custom Pumps Available To 200° F. Largest Selection of Flows, Pressures and Drive Options Available. Over 50 Years Of Diaphragm Pump Experience. One Piece Stainless Steel Diaphragm Bolts. Heavy Duty Pre-Formed Urethane Diaphragms.

Features

  • Max flow: 5 gpm
  • Max pressure: 275 psi
  • Includes 6010.23 control unit and 5094.76 gearbox with 3/4" hollow shaft for mounting to 3 to 6.5 hp gas engines
  • Port sizes: 3/4" HB inlet, 3/8" HB outlet, 5/8" HB bypass
  • Pump shaft rotation: CW and CCW
  • Diaphragms: 2, semi-hydraulic, Desmopan® standard Buna available
  • Housing: Anodized aluminum
  • Max fluid temperature: 140°F
  • Weight: 14 lbs

Parts breakdown

Diagram

Diagram parts

Parts list

  • Crankshaft
    • Ref No: 29
    • Part No: 0002E2
    • Qty Req: 1
    Our price: $172.81 List price: $208.20
  • Bearing (5033.A4)
    • Ref No: 132
    • Part No: 000601
    • Qty Req: 1
    Our price: $51.54 List price: $62.10
  • Seal (IOTA-20/GR)
    • Ref No: 160
    • Part No: 000711
    • Qty Req: 1
    Our price: $16.68 List price: $20.10
  • Diaphragm Bolt (KAPPA-15, KAPPA-18, IOTA-20, KAPPA-7/12V)
    • Ref No: 239
    • Part No: 010202
    • Qty Req: 2
    Our price: $14.86 List price: $17.90
  • Suction Barb (IOTA-20)
    • Ref No: 362
    • Part No: 0202A1
    • Qty Req: 1
    Our price: $8.47 List price: $10.20
  • Piston Sleeve (IOTA-20)
    • Ref No: 490
    • Part No: 020616
    • Qty Req: 2
    Our price: $77.52 List price: $93.40
  • Accumulator Head
    • Ref No: 565
    • Part No: 020831
    • Qty Req: 1
    Our price: $64.74 List price: $78.00
  • Pump Body (IOTA-20)
    • Ref No: 612
    • Part No: 020990
    • Qty Req: 1
    Our price: $213.56 List price: $257.30
  • Valve Retainer (IOTA-20)
    • Ref No: 655
    • Part No: 021104
    • Qty Req: 4
    Our price: $10.38 List price: $12.50
  • Ball Bearing
    • Ref No: 703
    • Part No: 021408
    • Qty Req: 1
    Our price: $44.82 List price: $54.00
  • Washer (IOTA-20)
    • Ref No: 789
    • Part No: 0030108
    • Qty Req: 1
    Our price: $5.31 List price: $6.40
  • Retainer Washer (IOTA-20)
    • Ref No: 790
    • Part No: 0030109
    • Qty Req: 2
    Our price: $8.55 List price: $10.30
  • Flange (IOTA-20)
    • Ref No: 903
    • Part No: 050147
    • Qty Req: 1
    Our price: $152.22 List price: $183.40
  • Crankshaft Adapter
    • Ref No: 906
    • Part No: 050105
    • Qty Req: 1
    Our price: $125.25 List price: $150.90
  • Air Valve Assembly
    • Ref No: 1122
    • Part No: 060816
    • Qty Req: 1
    Our price: $20.50 List price: $24.70
  • Key
    • Ref No: 1193
    • Part No: 080103
    • Qty Req: 1
    Our price: $3.57 List price: $4.30
  • Accumulator Diaphragm - Udor KAPPA-55
    • Ref No: 1295
    • Part No: 090308
    • Qty Req: 1
    Our price: $18.92 List price: $22.80
  • O-Ring
    • Ref No: 1370
    • Part No: 1101A2
    • Qty Req: 1
    Our price: $2.24 List price: $2.70
  • O-Ring
    • Ref No: 1373
    • Part No: 110152
    • Qty Req: 4
    Our price: $2.24 List price: $2.70
  • O-Ring
    • Ref No: 1388
    • Part No: 110136
    • Qty Req: 1
    Our price: $2.82 List price: $3.40
  • O-Ring
    • Ref No: 1405
    • Part No: 110110
    • Qty Req: 4
    Our price: $2.57 List price: $3.10
  • O-Ring
    • Ref No: 1406
    • Part No: 110117
    • Qty Req: 4
    Our price: $2.57 List price: $3.10
  • Mounting Rail
    • Ref No: 1453
    • Part No: 120217
    • Qty Req: 1
    Our price: $19.51 List price: $23.50
  • Piston
    • Ref No: 1575
    • Part No: 120513
    • Qty Req: 2
    Our price: $74.29 List price: $89.50
  • Piston & Rod Assembly
    • Ref No: 1681
    • Part No: 600086
    • Qty Req: 2
    Our price: $114.29 List price: $137.70
  • Valve Assembly
    • Ref No: 1705
    • Part No: 600604
    • Qty Req: 4
    Our price: $22.00 List price: $26.50
  • Washer
    • Ref No: 1843
    • Part No: 140307
    • Qty Req: 8
    Our price: $1.33 List price: $1.60
  • Washer
    • Ref No: 1845
    • Part No: 140310
    • Qty Req: 8
    Our price: $0.94 List price: $1.13
  • Washer
    • Ref No: 1847
    • Part No: 140312
    • Qty Req: 4
    Our price: $1.74 List price: $2.10
  • Washer
    • Ref No: 1875
    • Part No: 140401
    • Qty Req: 1
    Our price: $1.74 List price: $2.10
  • Connecting Rod Pin
    • Ref No: 1965
    • Part No: 150204
    • Qty Req: 2
    Our price: $14.86 List price: $17.90
  • Snap Ring
    • Ref No: 2049
    • Part No: 150611
    • Qty Req: 2
    Our price: $1.91 List price: $2.30
  • Connecting Rod (IOTA-20)
    • Ref No: 2141
    • Part No: 010356
    • Qty Req: 2
    Our price: $35.69 List price: $43.00
  • Oil Plug (O-Rings Sold Separately 110116)
    • Ref No: 2262
    • Part No: 160324
    • Qty Req: 1
    Our price: $10.04 List price: $12.10
  • Head
    • Ref No: 2314
    • Part No: 1604B8
    • Qty Req: 2
    Our price: $99.60 List price: $120.00
  • Bolt
    • Ref No: 2474
    • Part No: 180457
    • Qty Req: 4
    Our price: $1.99 List price: $2.40
  • Bolt
    • Ref No: 2477
    • Part No: 180467
    • Qty Req: 8
    Our price: $1.74 List price: $2.10
  • Bolt
    • Ref No: 2482
    • Part No: 180409
    • Qty Req: 12
    Our price: $2.24 List price: $2.70
  • Barb Nut
    • Ref No: 7330
    • Part No: 060429
    • Qty Req: 1
    Our price: $7.55 List price: $9.10
  • Piston Diaphragm Desmopan (Std.)
    • Ref No: 8119
    • Part No: 090341
    • Qty Req: 2
    Our price: $34.03 List price: $41.00
