Udor RO-250/CC Diaphragm Pump

Udor RO-250/CC Diaphragm Pump

Brand:
Udor
Weight:
75.0 lb
Item #
RO250CC

$2,063.16
$2,063.16 List Price: $3,751.20

We're here to help!

Let us know if you need assistance finding the right spray equipment

Earn 6,189 points with this purchase.

See Details

View full details

Product Overview

Udor RO-250/CC Diaphragm Pump (Replaced by ZETA-260/CC)

65 gpm, 300 psi.

Six diaphragm pump with mounting rails & a dual 1-3/8", six spline male PTO shaft.

UDOR RO Series Pumps Have Plasticized Aluminum Heads And Glass Filled Nylon Manifolds. Control Units Not Included.

Resources

Download Product Manual

Parts breakdown

Diagram

Diagram parts

Parts list

  • Connecting Rod Ring
    • Ref No: 6
    • Part No: 000108
    • Qty Req: 2
    Our price: $59.84 List price: $72.10
  • Crankcase
    • Ref No: 59
    • Part No: 000229
    • Qty Req: 1
    Our price: $603.74 List price: $727.40
  • Seal
    • Ref No: 156
    • Part No: 000702
    • Qty Req: 2
    Our price: $18.27 List price: $22.01
  • Diaphragm Bolt (BETA-150/200/240, OMEGA-140/170, RO-70/160/210/250/320)
    • Ref No: 238
    • Part No: 0010203
    • Qty Req: 6
    Our price: $18.59 List price: $22.40
  • Sleeve
    • Ref No: 489
    • Part No: 020614
    • Qty Req: 6
    Our price: $173.97 List price: $209.60
  • Oil Cap **Obsolete - no longer available. Must buy 603301 complete assembly**
    • Ref No: 540
    • Part No: 020898
    • Qty Req: 1
    Our price: $16.52 List price: $19.90
  • Pump Body (RO-210/250)
    • Ref No: 638
    • Part No: 020949
    • Qty Req: 1
    Our price: $826.68 List price: $996.00
  • BEARING
    • Ref No: 738
    • Part No: 021607
    • Qty Req: 1
    Our price: $219.12 List price: $264.00
  • Washer (RO-160/210/250)
    • Ref No: 802
    • Part No: 0030128
    • Qty Req: 2
    Our price: $107.07 List price: $129.00
  • Spacer Ring
    • Ref No: 838
    • Part No: 030259
    • Qty Req: 2
    Our price: $11.87 List price: $14.30
  • Bearing Flange (RO-160/210/250)
    • Ref No: 919
    • Part No: 050167
    • Qty Req: 1
    Our price: $144.92 List price: $174.60
  • Gasket
    • Ref No: 1083
    • Part No: 060549
    • Qty Req: 1
    Our price: $2.32 List price: $2.80
  • Diaphragm Buna-N (Opt.)
    • Ref No: 1291
    • Part No: 090302
    • Qty Req: 6
    Our price: $31.46 List price: $37.90
  • O-Ring
    • Ref No: 1365
    • Part No: 110101
    • Qty Req: 12
    Our price: $4.15 List price: $5.00
  • O-Ring
    • Ref No: 1371
    • Part No: 110107
    • Qty Req: 48
    Our price: $2.82 List price: $3.40
  • O-Ring
    • Ref No: 1382
    • Part No: 110129
    • Qty Req: 1
    Our price: $2.49 List price: $3.00
  • O-Ring
    • Ref No: 1401
    • Part No: 110158
    • Qty Req: 1
    Our price: $9.30 List price: $11.20
  • Mounting Rail
    • Ref No: 1461
    • Part No: 120238
    • Qty Req: 2
    Our price: $51.63 List price: $62.20
  • Discharge/Inlet Manifold
    • Ref No: 1503
    • Part No: 120342
    • Qty Req: 12
    Our price: $25.48 List price: $30.70
  • Piston
    • Ref No: 1569
    • Part No: 120506
    • Qty Req: 6
    Our price: $104.75 List price: $126.20
  • Valve Assembly
    • Ref No: 1709
    • Part No: 600608
    • Qty Req: 12
    Our price: $42.08 List price: $50.70
  • Oil Reservoir Assembly
    • Ref No: 1740
    • Part No: 603301
    • Qty Req: 1
    Our price: $68.23 List price: $82.20
  • Piston/Rod Assembly
    • Ref No: 1774
    • Part No: 601532
    • Qty Req: 6
    Our price: $226.67 List price: $273.10
  • Washer
    • Ref No: 1843
    • Part No: 140307
    • Qty Req: 2
    Our price: $1.33 List price: $1.60
  • Washer
    • Ref No: 18
    • Part No: 140309
    • Qty Req: 30
    Our price: $1.33 List price: $1.60
  • Washer
    • Ref No: 1845
    • Part No: 140310
    • Qty Req: 36
    Our price: $0.94 List price: $1.13
  • Connecting Rod Pin
    • Ref No: 1962
    • Part No: 150202
    • Qty Req: 6
    Our price: $21.00 List price: $25.30
  • Snap Ring
    • Ref No: 2046
    • Part No: 150602
    • Qty Req: 12
    Our price: $1.91 List price: $2.30
  • Connecting Rod
    • Ref No: 2154
    • Part No: 151921
    • Qty Req: 6
    Our price: $79.68 List price: $96.00
  • Manifold Tube
    • Ref No: 2187
    • Part No: 160116
    • Qty Req: 10
    Our price: $55.44 List price: $66.80
  • Plug
    • Ref No: 2282
    • Part No: 160350
    • Qty Req: 1
    Our price: $8.55 List price: $10.30
  • Head
    • Ref No: 2318
    • Part No: 160436
    • Qty Req: 6
    Our price: $171.64 List price: $206.80
  • Bolt
    • Ref No: 2465
    • Part No: 180403
    • Qty Req: 6
    Our price: $2.32 List price: $2.80
  • Bolt
    • Ref No: 2466
    • Part No: 180406
    • Qty Req: 3
    Our price: $2.24 List price: $2.70
  • Bolt
    • Ref No: 2478
    • Part No: 180468
    • Qty Req: 2
    Our price: $1.99 List price: $2.40
  • Bolt
    • Ref No: 2486
    • Part No: 180479
    • Qty Req: 36
    Our price: $2.41 List price: $2.90
  • Bolt
    • Ref No: 2582
    • Part No: 180504
    • Qty Req: 2
    Our price: $2.49 List price: $3.00
  • Bolt
    • Ref No: 2589
    • Part No: 180531
    • Qty Req: 2
    Our price: $1.91 List price: $2.30
  • Oil Reservoir Adapter
    • Ref No: 7247
    • Part No: 050191
    • Qty Req: 1
    Our price: $69.22 List price: $83.40
  • Washer
    • Ref No: 7600
    • Part No: 140336
    • Qty Req: 3
    Our price: $2.24 List price: $2.70
  • PTO Safety Shield (Optional)
    • Ref No: 7650
    • Part No: 121902
    • Qty Req: 1
    Our price: $41.83 List price: $50.40
  • Thru-Shaft Protector (Optional)
    • Ref No: 7653
    • Part No: 121915
    • Qty Req: 1
    Our price: $17.76 List price: $21.40
  • Diaphragm Desmopan (Std.)
    • Ref No: 8113
    • Part No: 090334
    • Qty Req: 6
    Our price: $52.21 List price: $62.90
