**The pricing shown does not include the Isuzu chassis**

Kings Sprayers builds Custom Lawn Trucks!  This truck is equipped with 4 tanks to spray from - 500/200/100/30 - and a 5th tank - 20 gallons - for water only. Up top there is a walkway to access the tanks along with a hinged door to close it off. Spray effectively utilizing a custom stainless steel valve bank clearly labeled to assist the operator in choosing which tank to pull from, agitate or bypass water to. Another custom feature is a sink with 12V pump on the driver side to wash your hands or clean equipment. The tanks are made from a co-polymer material - also known as poly welded in the industry. The decking is non-skid aluminum 6061 aircraft grade for longevity and safety of your crew. The pump is a Udor DELTA-75/GR coupled to a Honda GX390 13 HP Electric Start Engine. Dual Hannay electric hose reels and fully enclosed guides. Our trucks are fully customizable - please contact us for a free custom quote today

Kings Sprayers Open Top Lawn Truck - 500/200/100/30 with Custom Valve Bank & Dual Hose Reels **Sink and 20 Gallon Fresh Water Tank Included**

Model: KLTOT5002001003020D75E39E2

1. All Welded High Strength Co-Polymer Tank/Storage Boxes w/ 5 Yr Warranty
2. Non-Skid Aluminum Decking for Corrosion Resistance & Operator Safety
3. Long Life LED Lights, Flush Mounted & Sealed
4. 3” Tubular High Tensile Strength Steel DOT Bumper & Hitch Supports
5. 2” Receiver Style Hitch for Trailer Towing or Hitch Mounted Carriers
6. Impact Resistant Poly Welded Drop Tanks w/ Internal Baffles
7. Heavy-Duty Aluminum Subframe for Drop Tanks
8. Large Extra Deep Storage Boxes
9. Premium Honda Engines
10. Commercial Grade Roll-Up Doors
11. Chemical Resistant Poly Welded Tanks w/ Baffles & Large Fill Wells
12. UV Stabilized Co-Polymer Construction
13. No Rust, No Corrosion, No Paint, Stain Resistant & Easy to Clean
14. White Polymer Panels Dissipate Heat, Block Sun, Protect Equipment & Chemicals
15. Smooth Welded Seams Prevent Chemical Build Up & Bacteria Growth
16. Heavy Duty Construction w/ 1/2” Side Walls & 3/4" Base

Features:

• 500/200/100 Gallon Poly Welded Co-Polymer Tanks - 30 Gallon Poly Induction and 20 Gallon Poly Welded Co-Polymer Tank Included
• 13 HP Honda GX390 Electric Start engine
• Udor DELTA-75/GR Diaphragm Pump (20 gpm, 560 psi)
• Dual Electric Hose Reels - 400' of 3/8" ID w/ Fully Enclosed Guides
• Made in USA
• 6061 aircraft grade non-skid aluminum frame is lightweight, chemical resistant and will never rust or need painting
• Backup camera for added safety
• Stairs and handle to climb safely onto deck
• Rear mounted strobe lights
• Red & White reflective tape on bumper
• Manual air gap
• Spill kit with most common wear parts included
• Labels for operation and tailored video of operation

Additional Options:

• Electronic or cable controlled air gap
• Safety cones and holders
• Fertilizer spreader or backpack racks

5/5/1 Warranty:
5 year frame / 5 year tank / 1 year parts and labor (limited to manufacturer defects)
