Titan 12" Alum Reel with SS Manifold

Titan 12" Alum Reel with SS Manifold

Brand:
Titan
Weight:
51.0 lb
Item #
4312ES
1 review
Skip to product information
1 of 1

Titan 12" Alum Reel with SS Manifold

Titan 12" Alum Reel with SS Manifold

Brand:
Titan
Weight:
51.0 lb
Item #
4312ES
1 review

Regular price $777.00
Sale price $777.00 Regular price List Price: $1,295.00

Earn 2,331 points with this purchase.

View full details

Collapsible content

Product Overview

**We are currently experiencing delays on Titan products. Please contact us for current availability.**

**Hose guide shown in picture sold separately - please see part number 7212**

If you're looking for a new and reliable hose reel or already use other tools and machinery from Titan, pick up their 12" aluminum reel with SS manifold. It's especially practical if you already have the same model or need two reels, since they're designed so that two reels of the same width can be easily and efficiently stacked.

Manufacturer description

4312ES Titan 12" aluminum electric hose reel **Hose guide shown in picture sold separately** comes equipped with a stainless steel hub assembly. Lightweight and corrosion resistant, Titan reels are a great choice for multiple applications. Equipped with a 1/3 hp electric motor and push button for easy rewinding of hose. The 12" reel will hold up to 200' of 1/2" ID hose or 300' of 3/8" ID.

Features

  • Frame and discs: Aluminum
  • Distance between discs: 12"
  • Rewind: Electric
  • Manifold: Stainless steel
  • Hose capacity: 300' of 3/8" ID or 200' of 1/2" ID
  • Port sizes: 1/2" FNPT inlet and outlet
  • Max pressure rating: 5000 psi
  • Spool: PVC
  • Swivel: 1/2" FNPT Super Swivel
  • Motor: 1/3 hp electric, 12V power source required
  • Stainless steel tierods and fasteners
  • Resin bearing holders with stainless back plates for corrosion resistance
  • Prewired switch and solenoid
  • Bracket for switch and solenoid keeps them out of the weather
  • Rectangular design more easily accommodates a simple and inexpensive stacking kit as well as hose guide
  • Recommended hose guide: 7212 or 7252
  • Weight: 49 lbs

Parts breakdown

Diagram

Diagram parts
