Udor BETA-200/CC Diaphragm Pump

Udor BETA-200/CC Diaphragm Pump

Brand:
Udor
Weight:
200.0 lb
Item #
BETA200CC

$4,697.55
$4,697.55 List Price: $8,541.00

Earn 14,093 points with this purchase.

See Details

View full details

Product Overview

56 gpm, 700 psi.

Six diaphragm pump with control unit with adjustable pressure regulator, manual dump lever, dual ball valve outlets & pressure gauge. Has dual 1-3/8", 6-spline male PTO shaft.

UDOR BETA Series Pumps Have Brass Heads, Stainless Steel And Brass Manifolds, Steel Connecting Rods, Mounting Rails And A Dual 1-3/8" Six Spline Male Shaft.

Resources

Download Product Manual

Parts breakdown

Diagram

Diagram parts

Parts list

  • Seal
    • Ref No: 156
    • Part No: 000702
    • Qty Req: 2
    Our price: $18.27 List price: $22.01
  • Diaphragm Bolt (BETA-150/200/240, OMEGA-140/170, RO-70/160/210/250/320)
    • Ref No: 238
    • Part No: 0010203
    • Qty Req: 6
    Our price: $18.59 List price: $22.40
  • 1/2" Hose Barb
    • Ref No: 358
    • Part No: 020219
    • Qty Req: 2
    Our price: $10.29 List price: $12.40
  • Hose Barb Elbow (BETA-150/200/240)
    • Ref No: 378
    • Part No: 020284
    • Qty Req: 2
    Our price: $88.23 List price: $106.30
  • Piston Sleeve (BETA-200)
    • Ref No: 510
    • Part No: 020638
    • Qty Req: 6
    Our price: $190.24 List price: $229.20
  • Oil Cap
    • Ref No: 559
    • Part No: 020822
    • Qty Req: 1
    Our price: $16.52 List price: $19.90
  • Pump Body (BETA-200/240, RO-320)
    • Ref No: 652
    • Part No: 020965
    • Qty Req: 1
    Our price: $1,820.36 List price: $2,193.20
  • Bearing (BETA-200/240, RO-320)
    • Ref No: 740
    • Part No: 021609
    • Qty Req: 2
    Our price: $330.26 List price: $397.90
  • Bearing (BETA-150/200/240, OMEGA-140/170)
    • Ref No: 705
    • Part No: 021411
    • Qty Req: 2
    Our price: $401.06 List price: $483.20
  • Spacer (BETA-150/200/240, RO-320, OMEGA-140/170)
    • Ref No: 786
    • Part No: 0030102
    • Qty Req: 2
    Our price: $127.07 List price: $153.10
  • Diaphragm Washer
    • Ref No: 787
    • Part No: 030103
    • Qty Req: 6
    Our price: $13.61 List price: $16.40
  • Flange (BETA-150/200/240, OMEGA-140/170, RO-320)
    • Ref No: 902
    • Part No: 0050146
    • Qty Req: 1
    Our price: $308.59 List price: $371.80
  • Oil Reservoir Extension
    • Ref No: 932
    • Part No: 0501B1
    • Qty Req: 1
    Our price: $85.82 List price: $103.40
  • Barb Nut
    • Ref No: 1034
    • Part No: 060409
    • Qty Req: 2
    Our price: $9.55 List price: $11.50
  • Barb Nut
    • Ref No: 1036
    • Part No: 060448
    • Qty Req: 2
    Our price: $67.81 List price: $81.70
  • Gasket
    • Ref No: 1071
    • Part No: 060505
    • Qty Req: 2
    Our price: $1.83 List price: $2.20
  • Ball Valve-Right
    • Ref No: 1124
    • Part No: 060845
    • Qty Req: 1
    Our price: $54.53 List price: $65.70
  • Piston Diaphragm Buna (Optional)
    • Ref No: 1290
    • Part No: 090301
    • Qty Req: 6
    Our price: $40.26 List price: $48.50
  • O-Ring
    • Ref No: 1365
    • Part No: 110101
    • Qty Req: 12
    Our price: $4.15 List price: $5.00
  • O-Ring
    • Ref No: 1368
    • Part No: 110104
    • Qty Req: 12
    Our price: $2.57 List price: $3.10
  • O-Ring
    • Ref No: 1382
    • Part No: 110129
    • Qty Req: 1
    Our price: $2.49 List price: $3.00
  • O-Ring
    • Ref No: 1385
    • Part No: 110132
    • Qty Req: 1
    Our price: $6.97 List price: $8.40
  • O-Ring
    • Ref No: 1406
    • Part No: 110117
    • Qty Req: 1
    Our price: $2.57 List price: $3.10
  • O-Ring
    • Ref No: 1409
    • Part No: 110168
    • Qty Req: 1
    Our price: $5.81 List price: $7.00
  • O-Ring
    • Ref No: 1415
    • Part No: 110177
    • Qty Req: 2
    Our price: $2.82 List price: $3.40
  • O-Ring
    • Ref No: 1420
    • Part No: 110171
    • Qty Req: 1
    Our price: $10.29 List price: $12.40
  • Mounting Rail
    • Ref No: 1468
    • Part No: 120252
    • Qty Req: 2
    Our price: $60.26 List price: $72.60
  • Oil Reservoir
    • Ref No: 1492
    • Part No: 120330
    • Qty Req: 1
    Our price: $49.97 List price: $60.20
  • Elbow
    • Ref No: 1505
    • Part No: 120345
    • Qty Req: 1
    Our price: $144.92 List price: $174.60
  • Elbow
    • Ref No: 1506
    • Part No: 120346
    • Qty Req: 5
    Our price: $126.33 List price: $152.20
  • Elbow
    • Ref No: 1508
    • Part No: 120351
    • Qty Req: 6
    Our price: $143.67 List price: $173.10
  • Piston
    • Ref No: 1571
    • Part No: 120508
    • Qty Req: 6
    Our price: $107.90 List price: $130.00
  • Valve Assembly
    • Ref No: 1709
    • Part No: 600608
    • Qty Req: 12
    Our price: $42.08 List price: $50.70
  • Oil Reservoir Assembly
    • Ref No: 1741
    • Part No: 603302
    • Qty Req: 1
    Our price: $84.49 List price: $101.80
  • Washer
    • Ref No: 18
    • Part No: 140309
    • Qty Req: 9
    Our price: $1.33 List price: $1.60
  • Washer
    • Ref No: 1845
    • Part No: 140310
    • Qty Req: 5
    Our price: $0.94 List price: $1.13
  • Connecting Rod Pin
    • Ref No: 1962
    • Part No: 150201
    • Qty Req: 6
    Our price: $22.00 List price: $26.50
  • Snap Ring
    • Ref No: 2046
    • Part No: 150602
    • Qty Req: 12
    Our price: $1.91 List price: $2.30
  • Snap Ring
    • Ref No: 2052
    • Part No: 150616
    • Qty Req: 1
    Our price: $4.90 List price: $5.90
  • Piston Ring
    • Ref No: 2111
    • Part No: 150905
    • Qty Req: 6
    Our price: $16.85 List price: $20.30
  • Connecting Rod
    • Ref No: 2158
    • Part No: 151925
    • Qty Req: 6
    Our price: $51.29 List price: $61.80
  • Inlet Manifold Tube
    • Ref No: 2189
    • Part No: 160120
    • Qty Req: 4
    Our price: $83.17 List price: $100.20
  • Inlet Tube
    • Ref No: 2228
    • Part No: 160226
    • Qty Req: 2
    Our price: $98.77 List price: $119.00
  • Manifold Plug
    • Ref No: 2247
    • Part No: 160374
    • Qty Req: 1
    Our price: $13.70 List price: $16.50
  • Plug
    • Ref No: 22
    • Part No: 160344
    • Qty Req: 1
    Our price: $4.73 List price: $5.70
  • Head
    • Ref No: 2329
    • Part No: 160454
    • Qty Req: 6
    Our price: $523.56 List price: $630.80
  • Discharge Manifold
    • Ref No: 2361
    • Part No: 160522
    • Qty Req: 1
    Our price: $397.07 List price: $478.40
  • Bolt
    • Ref No: 2465
    • Part No: 180403
    • Qty Req: 6
    Our price: $2.32 List price: $2.80
  • Bolt
    • Ref No: 2473
    • Part No: 180454
    • Qty Req: 2
    Our price: $2.24 List price: $2.70
  • Bolt
    • Ref No: 2582
    • Part No: 180504
    • Qty Req: 6
    Our price: $2.49 List price: $3.00
  • Bolt
    • Ref No: 2584
    • Part No: 180506
    • Qty Req: 3
    Our price: $1.99 List price: $2.40
  • Bolt
    • Ref No: 2585
    • Part No: 180508
    • Qty Req: 48
    Our price: $3.74 List price: $4.50
  • Ball Valve-Left
    • Ref No: 5003
    • Part No: 060846
    • Qty Req: 1
    Our price: $54.53 List price: $65.70
  • Piston/Rod Assembly
    • Ref No: 5311
    • Part No: 601537
    • Qty Req: 6
    Our price: $240.12 List price: $289.30
  • Bolt
    • Ref No: 6000
    • Part No: 180507
    • Qty Req: 24
    Our price: $2.82 List price: $3.40
  • BAN DRIP VALV
    • Ref No: 6951
    • Part No: 000110
    • Qty Req: 2
    Our price: $276.64 List price: $291.20
  • O-Ring
    • Ref No: 7539
    • Part No: 1101D7
    • Qty Req: 24
    Our price: $4.32 List price: $5.20
  • PTO Safety Shield (Optional)
    • Ref No: 7650
    • Part No: 121902
    • Qty Req: 1
    Our price: $41.83 List price: $50.40
  • Thru-Shaft Protector (Optional)
    • Ref No: 7653
    • Part No: 121915
    • Qty Req: 1
    Our price: $17.76 List price: $21.40
  • Piston Diaphragm Desmopan (Standard)
    • Ref No: 8112
    • Part No: 090333
    • Qty Req: 6
    Our price: $71.13 List price: $85.70
