Udor RO-110 Diaphragm Pump (Replaced by ZETA-120)

Udor RO-110 Diaphragm Pump (Replaced by ZETA-120)

Brand:
Udor
Weight:
45.0 lb
Item #
RO110
Skip to product information
1 of 1

Udor RO-110 Diaphragm Pump (Replaced by ZETA-120)

Udor RO-110 Diaphragm Pump (Replaced by ZETA-120)

Brand:
Udor
Weight:
45.0 lb
Item #
RO110

Regular price $1,107.76
Sale price $1,107.76 Regular price List Price: $1,844.70

Free Shipping on Qualified Orders Over $100

In stock orders placed within

ship out same day. Learn more

Earn 3,323 points with this purchase.

View full details

Collapsible content

Product Overview

Udor RO-110 Diaphragm Pump (Replaced by ZETA-120)

29 gpm, 300 psi.

Three diaphragm pump with universal drive face, pulsation dampener & mounting rails.

UDOR RO Series Pumps Have Plasticized Aluminum Heads And Glass Filled Nylon Manifolds. Control Units Not Included.

Parts breakdown

Diagram

Diagram parts

Parts list

  • Retainer Ring (RO-70, RO-110)
    • Ref No: 2
    • Part No: 000102
    • Qty Req: 2
    Our price: $35.03 List price: $42.20
  • Crankshaft (RO-110)
    • Ref No: 11
    • Part No: 000260
    • Qty Req: 1
    Our price: $469.95 List price: $566.20
  • Accumulator Base
    • Ref No: 81
    • Part No: 000315
    • Qty Req: 1
    Our price: $148.57 List price: $179.00
  • Bearing (RO-110, ZETA-40, ZETA-85)
    • Ref No: 136
    • Part No: 000607
    • Qty Req: 1
    Our price: $94.62 List price: $114.00
  • Seal (KAPPA-33/43, RO-110, ZETA-40/85)
    • Ref No: 157
    • Part No: 000705
    • Qty Req: 1
    Our price: $23.99 List price: $28.90
  • Diaphragm Bolt (BETA-150/200/240, OMEGA-140/170, RO-70/160/210/250/320)
    • Ref No: 238
    • Part No: 0010203
    • Qty Req: 3
    Our price: $18.59 List price: $22.40
  • Sleeve
    • Ref No: 489
    • Part No: 020614
    • Qty Req: 3
    Our price: $173.97 List price: $209.60
  • Oil Cap **Obsolete - no longer available. Must buy 603301 complete assembly**
    • Ref No: 540
    • Part No: 020898
    • Qty Req: 1
    Our price: $16.52 List price: $19.90
  • Accumulator Head
    • Ref No: 557
    • Part No: 020820
    • Qty Req: 1
    Our price: $92.46 List price: $111.40
  • Pump Body (RO-110)
    • Ref No: 626
    • Part No: 020934
    • Qty Req: 1
    Our price: $500.49 List price: $603.00
  • Outlet Manifold (RO-110)
    • Ref No: 647
    • Part No: 025707
    • Qty Req: 1
    Our price: $148.16 List price: $178.50
  • Bearing
    • Ref No: 701
    • Part No: 021405
    • Qty Req: 1
    Our price: $127.07 List price: $153.10
  • Air Valve Cap (KAPPA-100/120, RO-70/110/160)
    • Ref No: 747
    • Part No: 021801
    • Qty Req: 1
    Our price: $3.07 List price: $3.70
  • SPACER
    • Ref No: 792
    • Part No: 030112
    • Qty Req: 1
    Our price: $15.11 List price: $18.20
  • SPACER
    • Ref No: 799
    • Part No: 0030124
    • Qty Req: 1
    Our price: $13.45 List price: $16.20
  • SPACER
    • Ref No: 833
    • Part No: 030252
    • Qty Req: 2
    Our price: $14.86 List price: $17.90
  • Nut
    • Ref No: 845
    • Part No: 030301
    • Qty Req: 6
    Our price: $1.91 List price: $2.30
  • Flange (RO-110, ZETA-40/85)
    • Ref No: 916
    • Part No: 050162
    • Qty Req: 1
    Our price: $181.77 List price: $219.00
  • Flange (RO-110, ZETA-40/85)
    • Ref No: 927
    • Part No: 050179
    • Qty Req: 1
    Our price: $161.02 List price: $194.00
  • Suction Nut
    • Ref No: 1055
    • Part No: 060450
    • Qty Req: 1
    Our price: $18.09 List price: $21.80
  • Air Valve Assembly
    • Ref No: 1122
    • Part No: 060816
    • Qty Req: 1
    Our price: $20.50 List price: $24.70
  • Key
    • Ref No: 1199
    • Part No: 080111
    • Qty Req: 1
    Our price: $5.64 List price: $6.80
  • Diaphragm Buna-N (Opt.)
    • Ref No: 1291
    • Part No: 090302
    • Qty Req: 3
    Our price: $31.46 List price: $37.90
  • Accumulator Diaphragm
    • Ref No: 1300
    • Part No: 090314
    • Qty Req: 1
    Our price: $27.89 List price: $33.60
  • O-Ring
    • Ref No: 1365
    • Part No: 110101
    • Qty Req: 6
    Our price: $4.15 List price: $5.00
  • O-Ring
    • Ref No: 1368
    • Part No: 110104
    • Qty Req: 1
    Our price: $2.57 List price: $3.10
  • O-Ring
    • Ref No: 1371
    • Part No: 110107
    • Qty Req: 6
    Our price: $2.82 List price: $3.40
  • O-Ring
    • Ref No: 1376
    • Part No: 110116
    • Qty Req: 1
    Our price: $2.57 List price: $3.10
  • O-Ring
    • Ref No: 1382
    • Part No: 110129
    • Qty Req: 1
    Our price: $2.49 List price: $3.00
  • O-Ring
    • Ref No: 1391
    • Part No: 110143
    • Qty Req: 1
    Our price: $5.31 List price: $6.40
  • O-Ring
    • Ref No: 1398
    • Part No: 110142
    • Qty Req: 1
    Our price: $2.82 List price: $3.40
  • O-Ring
    • Ref No: 1401
    • Part No: 110158
    • Qty Req: 1
    Our price: $9.30 List price: $11.20
  • O-Ring
    • Ref No: 1412
    • Part No: 110179
    • Qty Req: 1
    Our price: $6.06 List price: $7.30
  • O-Ring
    • Ref No: 1434
    • Part No: 1101D1
    • Qty Req: 1
    Our price: $5.81 List price: $7.00
  • Suction Elbow
    • Ref No: 1497
    • Part No: 120336
    • Qty Req: 3
    Our price: $31.04 List price: $37.40
  • Piston
    • Ref No: 1569
    • Part No: 120506
    • Qty Req: 3
    Our price: $104.75 List price: $126.20
  • Stud
    • Ref No: 1607
    • Part No: 120622
    • Qty Req: 3
    Our price: $3.57 List price: $4.30
  • Valve Assembly
    • Ref No: 1709
    • Part No: 600608
    • Qty Req: 6
    Our price: $42.08 List price: $50.70
  • Oil Reservoir Assembly
    • Ref No: 1740
    • Part No: 603301
    • Qty Req: 1
    Our price: $68.23 List price: $82.20
  • Piston/Rod Assembly
    • Ref No: 1798
    • Part No: 601524
    • Qty Req: 3
    Our price: $261.37 List price: $314.90
  • 6031.09 Pulsation Dampener
    • Ref No: 1811
    • Part No: 603109
    • Qty Req: 1
    Our price: $258.30 List price: $311.20
  • Washer
    • Ref No: 1843
    • Part No: 140307
    • Qty Req: 2
    Our price: $1.33 List price: $1.60
  • Washer
    • Ref No: 1844
    • Part No: 140309
    • Qty Req: 9
    Our price: $1.33 List price: $1.60
  • Washer
    • Ref No: 1845
    • Part No: 140310
    • Qty Req: 18
    Our price: $0.94 List price: $1.13
  • Connecting Rod Pin
    • Ref No: 1962
    • Part No: 150201
    • Qty Req: 3
    Our price: $22.00 List price: $26.50
  • Snap Ring
    • Ref No: 2046
    • Part No: 150602
    • Qty Req: 6
    Our price: $1.91 List price: $2.30
  • Connecting Rod
    • Ref No: 2149
    • Part No: 151916
    • Qty Req: 3
    Our price: $70.38 List price: $84.80
  • Suction Manifold
    • Ref No: 2185
    • Part No: 160113
    • Qty Req: 2
    Our price: $53.62 List price: $64.60
  • Suction Manifold
    • Ref No: 2226
    • Part No: 160222
    • Qty Req: 1
    Our price: $63.08 List price: $76.00
  • Plug
    • Ref No: 2282
    • Part No: 160350
    • Qty Req: 1
    Our price: $8.55 List price: $10.30
  • Head
    • Ref No: 2318
    • Part No: 160436
    • Qty Req: 3
    Our price: $171.64 List price: $206.80
  • Bolt
    • Ref No: 2481
    • Part No: 180407
    • Qty Req: 2
    Our price: $2.32 List price: $2.80
  • Bolt
    • Ref No: 2486
    • Part No: 180479
    • Qty Req: 6
    Our price: $2.41 List price: $2.90
  • Bolt
    • Ref No: 2581
    • Part No: 180503
    • Qty Req: 9
    Our price: $2.24 List price: $2.70
  • Bolt
    • Ref No: 2589
    • Part No: 180531
    • Qty Req: 2
    Our price: $1.91 List price: $2.30
  • Bolt
    • Ref No: 5949
    • Part No: 180472
    • Qty Req: 8
    Our price: $2.32 List price: $2.80
  • Hose Barb (RO-110)
    • Ref No: 7124
    • Part No: 025305
    • Qty Req: 1
    Our price: $12.45 List price: $15.00
  • Diaphragm Desmopan (Std.)
    • Ref No: 8113
    • Part No: 090334
    • Qty Req: 3
    Our price: $52.21 List price: $62.90
  • Mounting Rail - Right Side
    • Ref No: 8151
    • Part No: 120263
    • Qty Req: 1
    Our price: $55.44 List price: $66.80
  • Mounting Rail - Left Side
    • Ref No: 8152
    • Part No: 120264
    • Qty Req: 1
    Our price: $55.44 List price: $66.80
